KR-Ochang: UCLEM

NOTE: Results presented here are highly dependent on how models are configured in this experiment and may be subject to variable output formatting errors. Results are not intended to indicate the quality of any individual model, but to help participants better understand and improve modelling approaches in different urban environments.

Submitted metadata

• Baseline
• Detailed

Error metrics

flux	experiment	MAE	MBE	nSD	R	5th	95th	RMSE	cRMSE	AMBE	1-nSD	1-R	nSkewness	nKurtosis	Overlap
SWup	baseline	9.86768	0.0533388	0.94061	0.898432	1.66009	6.54899	21.2407	0.441134	0.0533388	0.0593914	0.101568	0.485388	1.04413	0.0881236
SWup	detailed	9.87851	1.24978	0.962921	0.89781	1.63329	2.78079	21.4714	0.445171	1.24978	0.037081	0.10219	0.471312	1.0338	0.0846366
LWup	baseline	27.2381	27.1003	1.21908	0.984997	8.1661	60.338	32.7843	0.290824	27.1003	0.219082	0.0150035	2.98797	0.287514	0.142944
LWup	detailed	31.4003	31.2926	1.26068	0.983023	9.189	69.596	37.7489	0.332803	31.2926	0.260678	0.0169765	3.33331	0.319798	0.159896
Qle	baseline	24.4943	0.605474	1.03492	0.715471	0.504137	16.6869	42.5106	0.76821	0.605474	0.0349171	0.284529	0.270819	0.689246	0.219562
Qle	detailed	24.0601	-1.04061	0.997182	0.716491	0.529437	10.1842	41.6195	0.75195	1.04061	0.00281878	0.283509	0.274212	0.692113	0.221945
Qh	baseline	22.2197	3.57873	0.739161	0.873071	16.3115	39.0991	34.1196	0.505647	3.57873	0.260838	0.126929	0.0695816	0.117533	0.369603
Qh	detailed	23.1846	-1.7581	0.625272	0.868763	16.9732	60.388	37.0735	0.55185	1.7581	0.374727	0.131237	0.0309193	0.000475514	0.431713

• MAE: mean absolute error (close to 0 is better)
• MBE: mean bias error (close to 0 is better)
• NSD: ratio of model to obs standard deviation (close to 1 is better)
• R: Pearson’s correlation (close to 1 is better)
• all others: closer to 0 is better

Link to variable definitions

subset_SWup_v0-9

out of range: baseline

• UCLEM Qle min value of -843.5098 is less than expected -700.0 [W/m2]

out of range: detailed

• UCLEM Qle min value of -849.1327 is less than expected -700.0 [W/m2]
